Case Study ByteIQ: Building an AWS Platform for Digital Health companies
Updated: Apr 30
ByteIQ is a digital health startup focused on big data, they planned to use AWS to run all products and leverage AWS security and compliance standards. ByteIQ worked with DNX Solutions to design, implement and support an efficient AWS platform which allowed them to achieve 30% cost savings compared to the projected costs.
ByteIQ asked DNX to provide a solid design and implementation of a fresh new AWS platform to operate the new product. The new environment was required to be secure by default to follow the high compliance standard for medical applications in Australia. The application consists of 3 different parts:
Application Data Storage/Processing
Application Client Module
This platform must have well-defined requirements to cover security, cost-efficiency, high availability. DNX uses the well-architecture framework to address application migration projects.
DNX Proposed Solution
Following the AWS Well-architected framework DNX proposed to build a AWS foundation and modernize the current applications leveraging Docker containers applying on top of it blue/green deployment strategy. Essentials features to a DevOps oriented culture.
DNX proposed a two phased project to address the requirements:
Phase 1 — AWS Foundation: Multi-account AWS platform using infrastructure as code and CICD Pipelines using the following AWS services:
AWS Organisations/Consolidated billing
Single Sign-on (SSO) using GSuite
Client VPN to connect to private resources
Multi-tier VPC (Public DMZ, Private and Secure subnets)
S3 bucket for staging data
KMS strategy to apply encryption at rest
AWS GuardDuty/CloudTrail/SNS Topics for alerting
Phase 2 — Application migration: All applications were migrated to Docker containers and deployed using AWS ECS with Spot instances:
AWS ALB/CloudFront/WAF for the application portal
AWS ECS workers for Data processing using CloudWatch Events
ASG for Containers using CPU Metric
ASG for EC2 using Memory Metrics
Zero Deployment Blue/Green using CodeDeploy
CICD Pipelines using Gitlab
DynamDB to store NoSQL data from medical clinics
RDS Aurora MySQL to store portal metadata.
During the first phase, the DNX team worked to deliver the AWS platform to support the project, and in the second phase DNX and ByteIQ team worked together to understand the best patterns to deploy the application stack.
The client application was written in Java and we design an integration to push data to S3 (encryption in transit and at rest) to send daily data consumption from medical clinics.
Once a group of files are saved in S3, a CloudWatch Event triggers the data processing pipeline using ECS, this process parses the unstructured data and saves to DynamoDB.
The application portal was migrated to Docker (PHP) and deployed behind an Application Load Balancer (ALB).
AWS CloudFront and Web Application Firewall (WAF) were added to ensure a better experience for users and at the same time enhance the application security.
The following high level design diagram summarises the used AWS stack:
DNX designed and implemented a CI/CD pipeline with zero-downtime where blue and green deployment architecture was applied as proposed initially. We Gitlab as the DevOps lifecycle tool and its CI/CD pipelines achieving the customer’s goals promoting a value stream to our costumers.
Migrating their workloads to AWS obtained a reliable, robust, secure and cost-effective cloud platform, allowing them to experiment on a breadth of new services for building a more competitive platform for their customers rapidly using continuous delivery concepts.
The main concept that drives data-related projects is how to transform data in insights to impact the business.
By using DNX services, ByteIQ could focus on their core business and leave the cloud platform challenges with us.
